Product Introduction

Model:

BTM-C802

Product Introduction:

Product Description : 1、Fully embedded Bluetooth 3.0+4.0; 2、High performance、low power consumption,dimension:30.4mmX15.26 mmX 2.40mm; 3、Supports enhanced audio and DSP Applications,support communication with smart ready

SLU0226DS
SLU0226DS
Product description
Product Description
1、Fully embedded Bluetooth 3.0+4.0;
2、High performance、low power consumption,dimension:30.4mmX15.26 mmX 2.40mm;
3、Supports enhanced audio and DSP Applications,support communication with smart ready devices;
4、The utility model can be widely used in a variety of Bluetooth devices;

Product Dimension


Product Introduction

Bluetooth Version Bluetooth 3.0+Bluetooth 4.0
Security Secure simple pairing and safer
BR/EDR connections 7
Class II 級
Radio Frequency 2.402GHz to 2.480GHz
Modulations GFSK, π/4-DQPSK and 8DPSK
Transmit power +8dBm
Receiver sensitivity -86dBm
Hardware Host interfaces UART,PIO,AIO,SPI,PCM etc.
GPIO 30mA
Discoverable/Connectable 0.05mA with deep sleep
Connected Audio streaming: 35mA
Max working current 30mA
Power supply 3.3 to 4.2V
Audio Features and Interfaces Codec Built in 64-bit stereo codec
Analog interface Dual ADC and DAC
Microphone Dual Microphone
Software codec Aptex and AAC
Echo cancellation CVC 5th generation
Environmental Temperature -40℃ to +85℃
Humidity Up to 95℃
Weight 1.2g
Environmentally Friendly ROHS Compliant
